Technical document of Y5278rotary kiln
Equipment name: Rotary kiln
Usage: Coalmining cement clinker of 6000t/d clinker production line
Specification: Φ5.2×78m(shell I.D×length)
Kiln support: 3
Inclination: 4%(sin)
Rotary speed of shell: Main driving: 0.4~4 r/min
Auxiliary driving: 0.146 r/min
Motor of main: ZSN4-450-12
Model of main motor: 800 power
Armature voltage: 660V
Rotary speed: 1000 r/min
Speed regulation range: 100~1000 r/min
Model of tachogenerator: ZYS-3A
Model of main motor: 22 power
Voltage: 110V
Speed regulation range: 0~2000 r/min
Model of main reducer: JH900C-SW305-28
Center distance: 1980mm
Speed ratio: 26.646
Model of lubrication oil station: XYZ-160GZ
Motor of oil pump: 7.5KW(2 units)
Electric heating period: 24KW/220V
Auxiliary driving device:
Motor model: Y280M-4
Power: 90kw
Voltage: 380V
Rotary speed: 1480r/min
Model of reducer: ZSY400-35.5-Ⅰ
Center distance: 880mm
Speed ratio: 35.795
Electric hydraulic block brake:
Quantity: 1 set
===========================================================================================================================================
